Yaskawa SGD-04AN 200V Servo Drives Σ-Series Servomotor SGM/SGD 400W

Yaskawa SGD-04AN 200V Servo Drives Σ-Series Servomotor SGM/SGD 400W

Наименование марки: Yaskawa
Номер модели: SGD-04AN
МОК: 1
цена: Negotiations
Подробная информация
Место происхождения:
ЯПОНИЯ
Рабочее напряжение::
200-230v
Рабочая мощность:
400 Вт
Масса:
2,35 фунта
Упаковывая детали:
Новая оригинальная коробка
Выделить:

Yaskawa SGD-04AN servo drive

,

200V Σ-Series servomotor

,

400W SGM/SGD servo drive

Описание продукта
Yaskawa SGD-04AN 200V Servo Drives Σ-Series Servomotor SGM/SGD 400W
Brand Yaskawa
Model Number SGD-04AN
Type Servo Drives
Working Voltage 200-230V
Working Power 400W
Warranty 1 Year
Security Module
  • Maximum applicable motor capacity: 0.05kw
  • Power supply voltage: three phase AC200V
  • Interface: MECHATROLINK-III communication command type (rotary servo motor)
  • Design sequence: B
  • Hardware specification: base mounting type (standard)
  • Optional module: security module
Safety Features

Complies with European EC standards based on ISO13849-1 EN and IEC 61800-5-2 safety functions. Enables best safety design for mechanical systems when combined with SGDV servo unit.

  • Torque Off Safe (STO)
  • Stop Safe 1 (SS1)
  • Stop Safe 2 (SS2)
  • Limited Speed Safely (SLS)

Equipped with 2 security functions that can be configured. Monitoring time and other parameters can be adjusted.

Motor Specifications
  • Rated torque: M/17N
  • Servo motor outside diameter: 290mm
  • Serial encoder: 20 bit absolute value type
  • Flange specifications: face C, reverse load side (lead)
  • Hollow structure for convenient wiring and piping
  • Instantaneous maximum torque: 6-600N/m
  • Maximum speed: 250-500r/min
Environmental Specifications
  • Using ambient temperature: 0-40°C
  • Excitation mode: permanent magnet type
  • Installation method: flange type
  • Heat resistance grade: A
  • Insulation withstand voltage: AC1500V 1 minute
  • Protection mode: IP42 (fully enclosed self cooling)
  • Environmental humidity: 20-80% (non-condensing)
Typical Applications
  • Semiconductor manufacturing equipment
  • Liquid crystal circuit board manufacturing equipment
  • Various inspection and test equipment
  • Electronic part packaging machines
  • IC information processors
  • Robotics
  • Various automated machinery
