Наименование марки: | Schneider |
Номер модели: | 140ert85410 |
МОК: | 1 |
цена: | Negotiations |
Manufacturer | Schneider Electric |
---|---|
Series | Modicon Quantum |
Marking | CE |
Product or component type | Multifunction input module |
Number of terminals | ≤ 40 |
Function of module |
• Status monitoring on discrete inputs
• Time and date stamped event logging
• Status logging counting 500 Hz
|
Time synchronisation protocol | DCF77 |
Product compatibility |
• Concept
• Unity Pro
|
Group of channels | 2 groups of 16 inputs process input |
Discrete input number |
• 1 discrete input(s) at 24 V clock signal input
• 32 discrete input(s) at 24...125 V process input
|
Switching voltage |
• 125 V at 1 mA for process input
• 24 V at 6 mA for process input
• 48 V at 2.5 mA for process input
• 60 V at 2.5 mA for process input
|
Power consumption in W | ≤ 7.5 W for process input |
Insulation |
• By optocoupler clock signal input
• By optocoupler between group of channels
|
Anti bounce filtering | Configurable from 0 to 255 ms |
Input state | Inversion configurable |
Acquisition time | 1 ms clock signal input |
Input current | 5 mA for clock signal input |
Electrical connection |
• Shielded cable, cable length: ≤ 1968.5 ft (600 m) for process input
• Unshielded cable, cable length: ≤ 1312.34 ft (400 m) for process input
|
Connections - terminals | Screw terminal block |
Local signalling |
• 1 LED green communication on the bus (Active)
• 1 LED green self test OK, module ready (R)
• 1 LED red fault (F)
• 32 LEDs status of inputs (1 to 32)
|
Current consumption |
• 0.07 mA at 24 V DC 140XCP90000 module
• 3 mA at 24...125 V DC external power supply per group of channel
• 300 mA at 5 V DC bus
|
